ORION Refrigerated Air Dryer ARX10HJ
Brand: ORION Japan
Made in: Thailand
Price: Contact Us for Quotation
ORION ARX10HJ air dryer is suitable for installation of compressed air drying for 10HP - 7.5kW air compressors, or used at production lines with compressed air flow to be treated below 1.1 m3/min.
Specification
Guide
Cataloge
| MODEL | ARX10HJ | |
| Air Processing Capacity | m3/min | 1.1 |
| Inlet Air Temperature | ℃ | 10~80 |
| Pressure Dew Point | ℃ | 3~15 |
| Ambient Temperature | ℃ | 2~43 |
| Operating pressure | Mpa | 0.2~0.98 |
| Weight | Kg | 35 |
| Pipe Connections | B | R1 |
| Power Source (50Hz) | V | 1ph220V |
| Power Consumption (50Hz) | kW | 0.37 |
| Refrigerant | R134A |
